Description
1, Recessed installation, clean and neat appearance.
2, Anti-glare design, soft and comfortable light.
3, High-quality COB light source, uniform illumination.
3, die-casting aluminum housing, stable performance and extended product life.
4, Mercury-free & eco-friendly, no UV/IR radiation, safe for daily use.
5, Conform CE, RoHS, FCC, SAA, PSE certifications.
Product Details:
| General data | General | Material | die-casting aluminum |
| Finish | white /black ( silver/black/gold reflector) | ||
| Electrical | Light efficacy | 95 lm/w | |
| Input voltage | AC100-240V | ||
| Power factor (PF) | >0.9 | ||
| Optical | CCT | 2700K/3000K/4000K/6000K | |
| Led type | CREE COB | ||
| CRI | >80/90 | ||
| Beam angle | 15°/24°/38° | ||
| SDCM | <3 | ||
| Function | Control | Non-dim./ Triac Dim. / DALI dim./ 0-10V dim. | |
| Tilting angle | / | ||
| Rotating angle | / | ||
| Durability | IP grade | IP20 | |
| Operating Temperature | 一20°C ~ +40°C | ||
| Lifespan | >50,000H(L90,Tc＝55°C) | ||
| Warranty | 3 years |
| Model | Power | Size(mm) | Model | Power | Size(mm) |
| WK-DL-A-6 | 6W | φ68*63mm open:60mm |
WK-DL-A-10 | 10W | φ85*80mm open:75mm |
| WK-DL-A-20 | 20W | φ105*95mm open:90mm |
