Description
Product Features:
1, The chip structure is simple and reliable, with low failure rates and wide compatibility with controllers and power supplies.
2, Flexibility & Customization: Bendable at any angle (up to 180°) for curved surfaces. Cuttable at 5cm/10cm marked intervals without damaging the circuit.
3, Color Options: Single-color (white 2200-6500K, red, blue, green, etc.)
4, Control Modes: Dimmable (supports PWM dimmers)
5, Protection Level: IP20, IP65, IP66, IP68.
6, Physical Specifications: Thickness 2-3mm, width 8-12mm, length 1m/2m/5m/10m (customizable).
Product Details:
| Product details: | LED type | 3528 smd |
| Model number | WK-FP3528-30D/60D/120D… | |
| PCB size (Wideth) | 8mm / 10mm | |
| Input voltage | DC 12V/24V | |
| LED qty | 30pcs/ 60pcs/ 120pcs…customizable | |
| Power Consumption | 2.4w/ 4.8w/ 9.6w… | |
| Color temperature | R/G/B / 2200-6500K | |
| CRI (Ra) | > 80/90/95 | |
| Beam angle | 120° | |
| Lm per each led | 6-7 lm | |
| IP grade | IP20/65/67/68 |
Applications:
1, General ambient lighting (living rooms, bedrooms),;
2, Decorative lighting for ceilings/walls,;
3, Backlighting for signs, or budget-friendly lighting projects that do not require high brightness.
