Description
Product Features:
1, Its ultra-compact chip size (2.2×1.6mm) makes the light strip extremely thin and flexible, allowing it to bend freely around narrow corners, curved surfaces, or small spaces (e.g., gaps in furniture, edge of thin displays).
2. CCT color tunable, white and warm white.
3, Flexibility & Customization: Bendable at any angle (up to 180°) for curved surfaces. Cuttable at 5cm/10cm marked intervals without damaging the circuit.
4, Color Options: Single-color (white 2200-6500K, red, blue, green, etc.).
5, Control Modes: Dimmable (supports PWM dimmers).
6, Protection Level: IP20, IP65, IP66, IP68.
7, Physical Specifications: Thickness 2-3mm, width 5/8/10mm, length 1m/2m/5m/10m (customizable).
Product Details:
| Product details: | LED type | 2216 smd |
| Model number | WK-FP2216D-120D/240D | |
| PCB size (Wideth) | 5mm/ 8mm / 10mm | |
| Input voltage | DC 12V/24V | |
| LED qty | 120pcs/ 240pcs | |
| Power Consumption(w/m) | 9.6 w/ 19.2w | |
| Color temperature | white & warm white | |
| CRI (Ra) | > 80/90/95 | |
| Beam angle | 120° | |
| Lm per each led | 7-8 lm | |
| IP grade | IP20/65/67/68 |
Applications:
1, Ambient lighting for cabinets, drawer lighting, under-counter lighting (low-brightness needs).
2, Decorative lighting for small electronic devices, or scenarios requiring hidden installation with strict space constraints.
