Description
Product Features:
1, Side-Facing Light Emission: The LED chips are arranged to perpendicularly to the strips surface (side-oriented), ensuring concentrated lateral illumination.
2, Silicone Encapsulation Advantages: Made of food-grade, high-transparency, IP67 waterproof protection, corrosion resistance, and UV resistance .
3, Structural Design: Flexible FR-4 is fully wrapped in silicone, resulting in a slim profile that balances flexibility and sturdiness. Minimum bending radius ≥10mm (single direction) allows adaptation to mild curves.
4, Optical Performance: Available in warm white, natural white , cool white , and RGB/RGBW variants. High CRI (Ra ≥80/90) . Beam angle: 120°–150°. high brightness and no dark spots.
5, Electrical Stability: Low voltage 12V/24V DC, effective power consumption , and high luminous flux .
6, Flicker-free : No video / mobile phone flicker. dimming (PWM ≥20kHz) supports brightness adjustment from 10% to 100%.
Product Details:
| Product details: | LED type | 2835 / 5050/ 3528/ 2216 smd; COB |
| Model number | WK-SPxx-xx | |
| Housing material | silicone | |
| Size | see [sideview size list] | |
| Input voltage | DC 12V/24V | |
| LED qty | customizable | |
| Power Consumption | based on led qty | |
| Color temperature | R/G/B / 1800-7000K/ RGB/ RGBW… | |
| CRI (Ra) | > 80/90/95 | |
| Beam angle | 120° | |
| Lumens per watt | >90 lm/w | |
| IP grade | IP 67/68 |
Applications:
1, Wall Washing & Architectural Lighting: Installed in wall recesses, ceiling cornices, or floor skirting to cast soft lateral light across vertical surfaces;Outdoor building facades, columns, or balcony edges to outline architectural contours at night without glare.
2, Indoor Decorative & Task Lighting: Cabinet & Shelf Lighting; TV/Monitor Backlighting.
3, Commercial & Retail Lighting: Retail Displays; Restaurant & Café Ambiance.
4, Outdoor Protected Areas: Patio & Pergola Lighting;Garden Edging.
5, Furniture & Custom Lighting: Bed Frame Lighting; Desk & Workspace Lighting.
